Flanged steel parallel tread wheel with ball bearings and steel axle. Wheel diameter 100mm, outer flange 115mm, tread width 25mm, hub length 35mm. Axle M30 x 62mm, Load capacity 1000kg.
Suitable for use with ( PFC ) Parallel flange channels.
Use our bespoke quote tool and a member of our team will provide you with a quote.
Flanged steel parallel tread wheel with ball bearings and steel axle. Wheel diameter 100mm, outer flange 115mm, tread width 25mm, hub length 35mm. Axle M30 x 62mm, Load capacity 1000kg.
Suitable for use with ( PFC ) Parallel flange channels.
| Wheel Material | Steel |
|---|---|
| Diameter (mm) | 100 |
| Flanged Diameter (mm) | 115 |
| Tread (mm) | 25 |
| Total Width (mm) | 35 |
| Bore Size (mm) | 25 |
| Bearing type | Ball |
| Nut Width | 19 |
| Thread Length (mm) | 62 |
| Axle Size | M30 |
