Grade 304 Pressed stainless steel fixed castor with a top plate fixing fitted with a red polyurethane tyred white nylon centred wheel with a roller bearing. Wheel diameter 125mm, tread width 34mm, overall height 158mm, top plate 135mm x 110mm, hole centres 105mm x 80mm. Load capacity 300kg
| Diameter (mm) | 125 |
|---|---|
| Fixing Option | Plate |
| Castor Type | Fixed |
| Height (mm) | 158 |
| Wheel Material | Polyurethane on Nylon |
| Colour / Shore Hardness | Red Polyurethane on Nylon Rim / 96 Shore A |
| Bearing type | Roller |
| Tread (mm) | 35 |
| Fork Thickness (mm) | 4 |
| To Suit Fixing Bolt (mm) | 10 |
