Fabricated swivel castor with a top plate fixing fitted with a cast iron wheel with ball bearings. Wheel diameter 100mm, tread width 50mm, overall height 150mm, top plate 150mm x 110mm, hole centres 105mm x 80mm or 121mm x 59mm. Load capacity 400kg.
Use our bespoke quote tool and a member of our team will provide you with a quote.
Fabricated swivel castor with a top plate fixing fitted with a cast iron wheel with ball bearings. Wheel diameter 100mm, tread width 50mm, overall height 150mm, top plate 150mm x 110mm, hole centres 105mm x 80mm or 121mm x 59mm. Load capacity 400kg.
| Diameter (mm) | 100 |
|---|---|
| Fixing Option | Plate |
| Castor Type | Swivel |
| Bearing type | Ball |
| Height (mm) | 150 |
| Plate Size (mm) | 150 x 110 |
| Hole Centres (mm) | 105/121 x 80/59 |
| To Suit Fixing Bolt (mm) | 12 |
| Wheel Material | Cast Iron |
| Colour / Shore Hardness | Black Painted Cast Iron |
