Fabricated swivel castor with a top plate fixing fitted with a cast iron wheel with ball bearings. Wheel diameter 150mm, tread width 50mm, overall height 190mm, top plate 115mm x 102mm, hole centres 92mm x 67mm and 76mm x 76mm. Load capacity 600kg.
Use our bespoke quote tool and a member of our team will provide you with a quote.
Fabricated swivel castor with a top plate fixing fitted with a cast iron wheel with ball bearings. Wheel diameter 150mm, tread width 50mm, overall height 190mm, top plate 115mm x 102mm, hole centres 92mm x 67mm and 76mm x 76mm. Load capacity 600kg.
| Diameter (mm) | 150 |
|---|---|
| Fixing Option | Plate |
| Castor Type | Fixed |
| Bearing type | Ball |
| Height (mm) | 190 |
| Plate Size (mm) | 115 x 102 |
| Hole Centres (mm) | 76/92 x 76/67 |
| To Suit Fixing Bolt (mm) | 10 |
| Wheel Material | Cast Iron |
| Colour / Shore Hardness | Black Painted Cast Iron |
