Fabricated swivel castor with a fixed plate fixing fitted with a 75 shore A ‘extra soft’ blue polyurehtane on cast iron centred wheel with ball bearings. Wheel diamater 250mm, tread width 80mm, overall height 314mm, plate size 175mm x 140mm, hole centres 140mm x 105mm. Load capacity 1400kg at at 4kph, 560kg at 10kph and 500g at 16kph
** FOR INTERNAL AND EXTERNALÂ TOWING USE**
| Diameter (mm) | 250 |
|---|---|
| Fixing Option | Plate |
| Castor Type | Fixed |
| Bearing type | Ball |
| Height (mm) | 314 |
| Plate Size (mm) | 175 X 140 |
| Hole Centres (mm) | 140 X 105 |
| To Suit Fixing Bolt (mm) | 14 |
| Wheel Material | Polyurethane on Cast Iron |
| Colour / Shore Hardness | Blue Ergonomic Polyurethane on Cast Iron Rim / 75 Shore A |
